Gas-insulated medium-voltage switchgear NXPLUS C 24 - blue GIS

Voltage up to

24 kV

Short-time withstand current up to 25 kA
Rated current up to 1250 A
Circuit-breaker switchgear

Download brochure NXPLUS C 24

ENLIT

Product information The new gas-insulated circuit-breaker switchgear NXPLUS C 24 with Clean Air is a single-busbar switchgear for the primary distribution level of up to 24 kV, 25 kA and 1250 A. The switchgear in the blue GIS portfolio are equipped with the proven Siemens vacuum technology and offer all the advantages of a gas-insulated switchgear. With the available typicals circuit-breaker, bus sectionalizer, and disconnector, the NXPLUS C 24 can be used in substations as well as in numerous power supply applications. Its hermetically sealed stainless-steel compartment makes the switchgear environmentally independent and its compact dimensions allow efficient use of space. The switchgear is maintenance-free and enables modern, innovative plant design and protection concepts thanks to digital protection and control devices and integrated sensors for measuring current and voltage.

Features of blue GIS

Description of NXPLUS C 24

- Up to 24 kV, 25 kA and 1250 A

- Circuit-breaker, bus sectionalizer, disconnector panel
- Single-busbar
- Gas-insulated
- Hermetically sealed
- Type-tested switchgear according to
IEC 62271-100 and IEC 62271-200

Clean Air
    - F-gas-free
    - Global warming potential < 1
    - Highly stable
    - Non-toxic
    - Non-flammable
    - For every application temperature

Customer benefits

- Environmental independence
- Compact design
- Maintenance-free design
- Personal safety
- Security of operation, reliability
- Economy, ecology

NXPLUS C 24 - blue GIS: Discover your benefits

blue GIS meets the expectations of the Siemens customers further on, for example, with respect to switchgear availability, maintenance-free design, personal safety, compactness, and environmental independence. Clean Air consists of the natural elements of the ambient air and is therefore free of F-gases, with a global warming potential <1, highly stable, non-toxic, non flammable, and suitable for every application temperature.
