SIMATIC ET 200eco PN
Extremely rugged Block IO
The SIMATIC ET 200eco PN is a compact block IO with PROFINET connection in IP 65/67 degree of protection for cabinet-free installation directly on the machine. Thanks to its fully-sealed zinc die-cast housing, the ET 200eco PN is mechanically very rugged and resistant to vibrations, dust, oil, or humidity. ET 200eco PN is the seamless supplement for applications with a high degree of protection in addition to the modular ET 200pro I/O family.
Especially rugged design
Small footprint
Comprehensive range of modules
Easy installation and setup
Channel by channel diagnostics
Integrated 2-port switch
With its fully-sealed zinc die-cast housing, the ET 200eco PN allows operation at an ambient temperature range from -40 °C to 60 °C and a vibration strength of 20 g.
The modules can be mounted head-on or rotated 90 degrees to the side.
The PROFINET connection with a 2-port switch is integrated into every module.
The SIMATIC ET 200eco PN can be flexibly expanded via PROFINET and supports both star and line topologies within a system. Furthermore, it enables users to profit from an integrated diagnostics concept and from the high performance of PROFINET. In addition an I/O Link master module is available.
The sensors and actuators, as well as power and bus are connected via the rugged M12 connection system.
The ET 200eco PN is available with two different enclosure designs:
Modules with 4 x M12 connection in a long and narrow design (30 x 200 x 37 mm)
Modules with 8 x M12 connection in a short and wide design (60 x 175 x 37 mm)
Digital Output Modules
There are 5 modules available:
- 8 DO 1.3 A via 4 M12 sockets, double assigned, long design
- 8 DO 0.5 A via 4 M12 sockets, double assigned, long design
- 8 DO 1.3 A via 8 M12 sockets short design
- 8 DO 2.0 A via 8 M12 sockets short design
- 16 DO 1.3 A via 8 M12 sockets, double assigned, short design
Failsafe digital In-/Output module
F-DI 8 x 24 VDC, 4xM12 / F-DQ 3 x 24 VDC/2.0A PM, 3xM12
Compact, very robust, encapsulated PROFINET periphery as block IO for processing of failsafe digital signals in IP65/67 degree of protection for mounting outside the cabinet and contacting with M12 interface technology.
It allows up to 8 (up to PL d/ SIL 2) resp. 4 (up to PL e/SIL 3) sensors in and three actors (up to PL e/ SIL 3) out to be connected. Actors are always connected or disconnected on two channels (plus/minus –switched).
Analog Input Modules and Analog Output Modules
There are three analog modules available:
- 8 AI with 4 inputs voltage/current and 4 inputs resistance/resistance thermometer/thermocouple via 8 M12 sockets short design
- 8 AI with 8 inputs resistance/resistance thermometer/thermocouple via 8 M12 sockets short design
- 4 AO with 4 outputs voltage/current via 4 M12 sockets long design
