RUGGEDCOM RX1510 family

Compact, cost-efficient and utility grade switches and routers

These modular and field replaceable multi-service platforms let customers to select from WAN, serial and Ethernet options – making them ideal for electric power, industrial, rail, and traffic control applications.

Find the right product for your needs

RUGGEDCOM Selector

Overview

Rugged communications for harsh environments

Designed for and put to the test under the harshest environments, RUGGEDCOM products meet and exceed recognized industry standards for performance in mission-critical applications.
RX1510 family

Certified for electric power, rail and transportation

With an IP30 degree of protection, these Layer 2 and Layer 3 switches and routers come without internal cooling fans in addition to being modular and field replaceable.

The RX1510, RX1511 and RX1512 do not use internal fans for cooling and support a wide temperature range of -40° C to +85° C. Their modular and field replaceable platform lets customers select from WAN, serial and Ethernet options – making them ideally suited for power utilities, the industrial plant floor, and rail/traffic control systems.

Products at a glance


RX1510
RX1511
RX1512
Description
Compact, modular Layer 2 and 3 switch and router
Compact, modular Layer 2 and 3 switch and router
Compact, modular Layer 2 and 3 switch and router
Hot Swappable Modules
4
2
2
Fast Ethernet Ports
Up to 24
Up to 12
Up to 12
Gigabit Ports
Up to 8
Up to 4
Up to 4
APE1808 Ports
Up to 2
Up to 2
0
10 FL Ports
Up to 12
Up to 6
Up to 6
T1/E1 Ports
Up to 4
Up to 4
Up to 4
Cellular Ports
Up to 8
Up to 4
Up to 4
Serial Ports
Up to 24
Up to 12
Up to 12
Operating Temperature Range
–40°C to +85°C
–40°C to +85°C
–40°C to +85°C
Power Supply
2 x (24 VDC, 48 VDC or HI)
1 x (24 VDC, 48 VDC or HI)
1 x Internal (10-72VDC)
Find out more technical data or configure the product

Visit the industry mall

Technology that meets industry requirements

True to their name, RUGGEDCOM solutions are built tough – delivering error-free communications under high levels of electromagnetic interference in extreme temperatures and over long distances. See how RUGGEDCOM solutions have been put to the test. Discover special features, examples of international standards compliance, and more.

Further information

The knowledge and support you need, when you need it

Get a detailed overview of all Siemens has to offer – from RUGGEDCOM product information to support and services.
Professional Services for Industrial Networks

Professional services for industrial networks

It’s easy to acquire a top-of-the-line industrial communication network when you’re backed by our first-class network components and strong network design expertise. Work directly with us and our certified Solution Partners to help develop a network solution tailored to your needs.

Industrial networks education

Industrial networks education

Need in-house specialists? Participate in Siemens industrial networks training program and earn the subsequent certification aligned with international Industrial Ethernet standards.

Warranty information

Gain an overview of the general terms and conditions of sale for RUGGEDCOM products.

References

Proven technology

Day in and day out, RUGGEDCOM products perform without fail under extreme conditions around the world. Read on to find out more.

Contact

Rugged communications equipment for harsh environments

For more information about RUGGEDCOM, please contact our experts who will be pleased to assist you.

Would you like to know more?

Contact us now
