Options for WinCC Open Architecture

Get SIMATIC WinCC Open Architecture tailored to your requirements

SIMATIC WinCC Open Architecture is expandable with numerous options. The industry-specific functions are proof of the development’s marketability. These functions were developed during the course of various projects and have now been incorporated as options within the product.

Brochure: "SIMATIC WinCC Open Architecture at a glance"

Download PDF

Product range

The Options for WinCC Open Architecture at a glance

A comprehensive portfolio of options makes WinCC Open Architecture a system to cope with any use case in the field of SCADA applications.

Smart Analysis using SmartSCADA

Allows the assessment of plants by Key Performance Indicators (KPI).
The subsequent optimization is carried out using statistical methods based on "R".



  • Easy integration of statistics in WinCC OA projects
  • All operations inside SCADA, without any programming
  • Guided way to train the model
  • “R” operations inside SCADA environment



Data mining is used to select relevant data from a large amount of data. Here the connections and dependencies between different process values are recognized and used for further classification. When classifying the selected data, results are linked and states are automatically recognized and named by the user. Statistical models are generated from this analysed data. These models can then be used for optimization in the plantThis can be done both with historical data and with real-time data.
In addition to the existing KPI, data mining and classification functions, SmartSCADA also provides a generic interface to "R", which allows data from the SCADA system to be processed directly using statistical methods. "R" is a free programming language for statistical data analysis.


Use cases

  • Root Cause Analysis
  • Define KPIs, assign KPIs to devices with one click
  • Find dependencies by using correlation, find timeframes by filtering values, direct handover to statistical calculation
  • Classification based on a statistical model
  • Reuse model any time e.g. for new KPIs


Mobile User Interface for iOS and Android

Increasing globalization and mobility require systems for worldwide application which enable mobile access to plant information at any time, in any location.
The mobile user interface from SIMATIC WinCC Open Architecture is a mobile client for iOS and Android devices which offers the same possibilities and functionality as a standard client. With the definition of optional device classes stating the width, height and orientation of the different displays, optimum depiction on mobile devices is guaranteed.


Mobile devices are managed and administered at the WinCC OA Server. Project data is automatically distributed through the WinCC OA server, enabling integrated engineering completely without the need for programming. To guarantee secure communication, the mobile UI can also communicate using SSL encryption. Installation is simplicity itself: The app is simply downloaded from the relevant store and is immediately ready for use.



  • Simple installation
    - Download the app from the relevant store (Apple AppStore for iOS and Google Play Store for Android)
    - Start using straight away
    - Short time-to-market
    - Maintenance-free
  • 24/7 online access – from any location
  • Secured communication using SSL encryption


  • Automatic distribution of project data through the WinCC OA server
    - Integrated engineering
    - No programming required
  • Device administration and management at the WinCC OA server to register and enable mobile devices
  • Definition and assignment of optional device classes with the width and height of the different mobile devices
    - Display and administration of available devices per panel
    - The dimensions of the defined device classes are displayed in the GEDI (by means of a template)
  • Automatic scaling depending on the DP

Supported operating systems for mobile devices

  • iOS 9 or higher
  • Android KitKat 5.1 or higher

Secure data transmission

The Mobile UI communicates via SSL encryption.



The Mobile UI is available for iOS devices from the iOS 9 iTunes App Store® and for Android devices from Android KitKat 5.1 in the Google Play Store®.

Process visualization for mobile devices

With the mobile app SIMATIC WinCC OA OPERATOR, you can monitor and control your system easily from your smartphone or tablet. SIMATIC WinCC OA OPERATOR displays the process data, availability and status of your system. Operating personnel have 24/7 online access to the system and can react instantly thanks to an immediate alert function. This saves precious time and ultimately enhances system availability.



The main functions at a glance

  • Home screen with widgets, the latest alarm and two important project values

  • Alert screen with filtering and sorting options

  • Trending of single values even with compressed values

  • Lists of self defined groups for displaying values and commands

  • Map with locations of the different plants/facilities with filtered alarmsPhonebook function to contact other users direct



Simple and intuitive operation


To ensure that the user can monitor and control the system easily and intuitively, emphasis was given to usability throughout the app's development.


The app comprises five elements:


  • The home screen displays a general overview. It shows the two most important process values and the most recent alert. Additionally, up to 40 widgets can display; these can contain process values and status information on the WinCC OA system and its users. The additional alarm line on the home screen in the iPad version makes for superb ease of use.
  • The alert screen displays acknowledged and unacknowledged alerts which, depending on the user's authorization status, can be acknowledged. Sorting and filtering functions allow a clear overall view of data in the entire system.
  • The value groups display all data point elements in the respective group. The detail screen for each group displays the data point element, time-stamp and trend. By rotating the mobile device, the trend can be displayed in landscape format. The user can toggle between the various time ranges and zoom in on them.
  • The command groups section allows the appropriately authorized user the capability to modify the values.
  • The locations section provides an easy-to-read map showing the locations of installations within the overall system and also indicates the sum alerts for each location.
    The detail screen for each location displays the exact location using satellite imagery, the sum alert, a description of the location, as well as the alerts, values and command groups of the respective location.


Easy-to-use wizard for configuring the app

For quick and easy configuration of the app and its content, a special wizard has been developed. Drag and drop support allows the user to transfer the selected data point elements on to the screen and configure their preferred presentation mode. A total of 40 data groups, each with 40 data point elements are configurable. This means that with SIMATIC WinCC OA OPERATOR, the user can monitor and control a total of 1,600 data point elements.


Ultralight Client UX

This is a client for desktop applications based on HTML5 technology. There is no need to install SIMATIC WinCC Open Architecture or any plug-in. The aim of this client is to display WinCC OA on desktop PC’s with the integrated browser. It supports Microsoft EDGE, Internet Explorer, Google Chrome and Mozilla Firefox.

Desktop UI

This client provides a user interface, which runs in a web browser, with the same functionalities as a standard user interface. This enables a flexible remote access to the system, without installing SIMATIC WinCC Open Architecture.

It is installed like an app, the installation package is distributed via the WinCC OA webserver and runs as a stand-alone UI (not a plugin).  There is no need to install the UI from DVD or to install a browser plugin. All panels are cached locally via the WinCC OA webserver.
The new Desktop UI startup interface allows the user to choose the project and server combination similar to the Mobile UI.  A common device management for Mobile and Desktop UIs is provided.

The Desktop UI is available for Windows and Linux, and for browsers (EDGE, IE, Chrome, Firefox).

WinCC OA Web server

From any standard web browser, you can access and also interactively edit data via the intranet and Internet. This helps solve system monitoring tasks with cutting-edge Internet technology and mobile communication for the user's benefit.

  • The web server offers unrestricted access to all WinCC OA resources

  • Standard HTML pages, e.g. the alarm page, allow display and operation of the system via mobile devices

  • Current status information from the system are available on the intranet and around the world via the Internet

  • Encrypted communication via HTTPS

  • Cross-platform (Windows, Linux, ...) deployment

Web-based reporting using SOAP

Reporting is a key task of a SCADA system. Therefore this function is a particular focal point of SIMATIC WinCC Open Architecture.
A web-based reporting using a standardized SOAP (Simple Object Access Protocol) reporting interface is implemented. This allows reporting tools from third-party suppliers to be used without any additional effort. Reporting is further simplified by the additional provision of BIRT templates and pre-defined reporting data.

  • Web-based Reporting Interface (SOAP)
    - ECLIPSE BIRT (templates are provided)
    - Crystal Reports
    - SIMATIC Information Server (examples are provided)
    - Microsoft Excel

  • Online values, history

  • Compressed data, SQL, alarms

  • Diagnostics tools

  • Audit trail

Integrated Video management

WinCC OA VIDEO enables you to integrate complete video management functions natively into a SCADA project. This native integration allows the SCADA user to configure the video hardware and software in the same manner as the classical automation hardware.

The vendor neutral video standard ONVIF 2.0 (Open Network Video Interface Forum) is integrated in WinCC OA VIDEO, which allows the connection to different video hardware.

WinCC OA VIDEO is used to visualize video components and control cameras and PTZ (pan/tilt/zoom) cameras either by means of a control panel or using a keyboard and mouse. Because of this, comprehensive monitoring and control of complex devices (e.g. traffic control devices) is possible from a single operator station. This ensures that problem situations can be identified at an early stage and operators can react to these appropriately.

The combination of SCADA and video surveillance is more cost effective than using separate video interfaces, and additional maintenance and operational expenditure are reduced. It also reduces training time for operators.

WinCC OA VIDEO can be integrated into any existing WinCC OA application in Windows or Linux and it can be configured and expanded online. In accordance with the WinCC OA concept, it can be set up as a redundant uni



  • Software based, digital and vendor neutral video management system
  • Native integration of video management functions into a SCADA project
  • Integration of the vendor neutral video standard ONVIF (Open Network Video Interface Forum)
  • The configuration, operating messages and commands are stored in data points
  • Integrated in the WinCC OA setup
  • Freely scalable
  • Fits flexible to project requirements
  • Can be redundant
  • Fully integrated into the SCADA environment - can be integrated into any application WinCC OA as simple subproject It can be operated in parallel to the SCADA system in a common system, as well as a separate system in the composite system as a distributed system
  • WinCC OA systems in the composite system can display live- or playback images in their user interfaces
  • VIDEO can access all process data in the composite system, respond to its changes and allow so an easy interaction between video and automation technology


  • Consistent and central operation
  • Tight integration of video and SCADA functionality
  • Connection to different video hardware
  • Cost savings in operation and maintenance


  • Integrate video streams in the network via ONVIF 2.0 interface
  • Display of live images via video widget in WinCC OA screens
  • Video recorder: a pure software-based recording system for recording of video images, that works with standard hardware components as a recording medium, is provided
    - Redundant recording
    - Load Balancing
    - Loop recording including event-driven setting of an overprint lock
    - Event-driven recording with pre- and post-time
    - Recording for the time period of camera switching
    - Export of the recorded video streams including time information
    - Synchronous playback of several recordings
    - Recording directly on the SCADA server (for small systems)
  • Interfaces to PTZ (pan/tilt/zoom) cameras
  • Standard graphic object library for easy creation of SCADA screens with video objects
  • Automatic switch to camera image in case of alarm
  • Insertion of free configurable alarm text in the video stream
  • Free configurable image sequencer
  • Interface to RTS-P server
  • Use of control console

Enhanced functions with display server

  • Software multi-decoder for realization of a video wall with standard-PC hardware
  • Variable video grid: 1, 4, 6, 12 or 24 video streams
  • Free scalable display server windows
    - Scalable through multi-monitor support
    - Scalable through parallel operation on one video wall
  • SCADA graphic object for the configuration of the video wall

Reducing costs and increasing efficiency in building automation

Vendor-independent and object oriented; the common factor between the building automation communications protocol BACnet and the SCADA system SIMATIC WinCC Open Architecture. The WinCC OA BACnet package unites building control system and superordinated SCADA system. Offering direct access to the automation level, making WinCC OA BACnet the ideal solution for managing large and/or distributed facilities and properties.

Centralized operations and integration of all systems is a significant prerequisite for satisfying the efficiency and energy provision demands of facility and property management. The development of WinCC OA BACnet, a native BMS solution, addresses a wide spectrum of such customer requirements and demands. As WinCC OA BACnet is designed for an unlimited number of BACnet objects, and is especially suitable for complex projects in industry, airports, universities, hospitals, trade fairs etc.
A further advantage is that WinCC OA BACnet run both under Windows and Linux systems.

In comparison with island solutions, the virtually seamless compatibility between SIMATIC WinCC Open Architecture and BACnet is the major advantage of the tool. Connected to the automation level network WinCC OA BACnet recognizes all BACnet objects existing in the network through the WinCC OA BACnet browser and automatically creates these in SIMATIC WinCC Open Architecture, meaning the data is only present once in the system and can be efficiently processed online, offline or in mixed operation using a quick and efficient engineering toolkit.


The WinCC OA BACnet EDE importer with version management offers direct online data import from BACnet. Furthermore, with WinCC OA BACnet functional differences between individual device profiles are equated in SIMATIC WinCC Open Architecture on the application level. WinCC OA BACnet supports a multitude of BACnet services such as data sharing, scheduling, device and network management as well as alarm and event notification; trending is also available as an option.

WinCC OA BACnet not only fulfills the BACnet vision, rather also offers a higher degree of functionality and efficient engineering compared with other conventional SCADA approaches.

The main task of the scheduler is to allow you to create, parameterize and administrate a number of schedules of either time or event triggered actions.
By using the scheduler a set of specific actions can be triggered by defining simple or complex conditions. You can define actions like:

  • Setting the value of a data point element to a predefined value

  • Showing a pop-up message

  • Initiating an alert in the alert screen

  • Setting values via recipes or

  • Executing a user-defined script


A scheduler condition can consist of:

  • Only one date

  • a set of dates

  • periodic events

  • a date combined with a value condition

  • only a single value condition etc.

The scheduler can be utilized in wide range of industries (e.g. building automation, facility management, wastewater treatment plants, ...) and can be deployed to perform the following tasks:

  • Heat- and climate control

  • Light control

  • Alarming issues

  • Switching between different operational modes

  • Recipes (time controlled activation of recipes)

  • Changing responsibilities (on-call service teams)

  • Time-dependent maintenance

  • Reminder function for operational staff

  • Cyclic diagnostics/reports

  • Automatic checking sequences (weekly siren test etc.)

  • Time-dependent and/or value dependent change of set points

When a relatively large number of input/set point values need to be transferred from the control system to the peripheral devices, then a recipe management system can simplify this process significantly. WinCC OA Recipes provides a range of user-friendly functions that meet all the following requirements:

  • New recipes can be created at runtime or obsolete recipes deleted

  • The recipe type can be changed at runtime and the changes adopted in all recipes of this type

  • All essential operations are also available as CTRL functions and can therefore also be used in customized panels

  • In addition, recipes can be imported, exported and edited as CSV files (e.g. using Excel)

  • Online values from a process display can be saved in an existing or new recipe

  • There is no limit to the number of recipes for one recipe type

  • An automatic test is performed to check the validity of the recipe type and that all elements of the recipe are defined

  • Can be used also in distributed systems

Ideal visualization and control of Large Scale Systems

GIS Viewer enables the visualization of SIMATIC WinCC Open Architecture objects in distributed systems on a map. This feature provides numerous advantages, particularly in geographical distributed systems, like in Water, Traffic, Oil & Gas or Energy.

The GIS Viewer allows widely distributed plants to be easily visualized geographically on a map. Individual geographic areas can be precisely monitored through automatic or manual zoom right down to the device level. Should system components be in warning or alarm status this is signified by colors, forms, symbols, or characters on the respective map, allowing fast and precise navigation to the interruption. The solution gain more informative value through combination of cartographic information with actual status signals of the plant. A much more efficient project design is also achieved through dynamic map material rather than static map frames.

With the used data and maps the SIMATIC WinCC Open Architecture objects become reality in the layers – any numbers of layer definable. Data and maps are available at many different vendors (e.g.: ESRI - Environmental Systems Research Institute). GIS Viewer provides automatic zoom to upcoming alarms and warnings or easy navigation to any user interface, alarm and event screen. It is directly linked to related alarms and therefore GIS Viewer is perfectly integrated into the SCADA application

The WinCC OA CommCenter stands for innovative alarm management, alarm-remote trans- mission, and communication. SMS and Email are covered by the Communication Center.



  • Fast and reliable information about alerts
  • Comprehensive recording about states and conditions
  • Integration into existing systems
  • Bi-directional communication with the control room
  • Acknowledgement of alerts
  • Simple configuration and handling
  • Integrated duty plan and on-call service management
  • Complete integration in WinCC Open Architecture and therefore no additional tools necessary




  • Forwarding of alarms to on-call service management teams

  • Different transmission media
    - Short messages (SMS)
    - E-mail

  • Acknowledgement of receipt

  • On-call service plan

  • Active alarm status request

  • Cyclic information

  • Negligible configuration effort

Advanced Maintenance Suite (AMS)

Advanced Maintenance Suite (AMS) is an easily configurable tool for efficient planning, management, execution and control of maintenance work and breakdown remedy. It saves money, improves the quality of your system and can be expanded by SCADA functionality.

With AMS

  • you will have an overview of all events (Event overview)

  • you will generate work orders automatically (Work order)

  • you will select the proper technicians (Technician selection)

  • the process routines will be recorded for each application (Action plan)

  • you define what will happen if nothing happens (Escalation methods)

  • you can optimise your spare parts inventory (Spare parts optimisation)

  • you will secure the consistent quality of the system (Quality assurance)

  • you can retrieve knowledge on push of a button (Knowledge database)

  • you will control your maintenance tasks more efficiently (Maintenance management)

For each scheduled maintenance task or spurious error event, checklists can be produced beforehand with detailed work instructions, possibly required spares, system and equipment documentation, as well as regulations.
When such an event occurs in a system, AMS automatically triggers a work order, which a dispatcher then assigns to a maintainer with the appropriate qualification. AMS informs the maintainer who can start immediately on the assigned task.
By means of the spare parts codes and tool names recorded in the system, stores are informed simultaneously with the maintainer and can start their preparations at the same time.
The checklist is systematically worked off by the maintainer, AMS registers the completed tasks and the work order is successfully closed off with additional information from the maintainer.
If the instructions and information provided in a checklist do not lead to solving the problem, the maintainer has the possibility to query a database for possible solutions. At any time, the parties involved can deposit solutions in this database or search for descriptions of solutions that fit an actual situation.
The deposited solutions form the basis for a later reworking of the checklists and ensure the transfer of knowledge between staff members, service providers or both.
In order to systematically reduce reoccurrences of similar failures, problem, cause and remedy are recorded at the completion of each work order. This allows to conduct, at a later stage, analyses in the form of reports, derive measures for quality assurance and obtain accounting information.
If work orders are not completed within a defined time period, AMS automatically controls their escalation. In this way, no order can be overlooked and completion on time is guaranteed.

Downloads & Support

Further information

All about SIMATIC WinCC Open Architecture at a glance

Support Services

Within the framework of Online and Technical Support, Siemens Industry offers a wide range of services. Online Support, Technical Support, Application Support and Managed System Services.

Spare Parts Services

Siemens Industry's spare parts services are available worldwide and provide smooth and fast supply of spare parts – and thus optimal plant availability.

SITRAIN - Digital Industry Academy

Further education for all Siemens industrial products - directly from the manufacturer, individually, with the latest methods.


The direct way to your SIMATIC SCADA contact

You have questions concerning our SIMATIC SCADA systems? You want to discuss your specific challenges with us or are looking for the right project partner? Contact our regional offices – we are looking forward to hearing from you!

Just contact us

Contacts in the region
