SIMATIC Field PG

Latest generation of high-performance programming devices in a semi ruggedized notebook design

The SIMATIC Field PG with its robust magnesium housing is well prepared for mobile applications in harsh environments: Shocks and vibrations, but also electromagnetic disturbances in machine-oriented industrial environments do not affect the device.  Equipped with all important automation interfaces, the connection to machines and systems is possible via PROFIBUS as well as via two fast PROFINET interfaces. Serial connections are also supported. The SIMATIC memory cards can be deleted and programmed directly in the corresponding slots. The pre-installed engineering software makes the SIMATIC Field PG ready for immediate use. The TIA Portal simplifies fast and efficient configuring, commissioning, service and maintenance. The SIMATIC Field PG is available in two performance choices: Comfort and Advanced

Promotion: TIA Portal Options + TIA Portal on SIMATIC Field PG M6

Promotion: TIA Portal Options + TIA Portal on SIMATIC Field PG M6

  • You need the TIA Portal engineering for SIMATIC Controllers, HMI Panels and you have to deal with safety related applications?
  • At the same time you have to maintain and service older machines and plants?
  • You want to go with the flow, and test your project without PLC hardware?
  • The offer to save engineering time by automatically generating HMI images also appeals to you.
  • You and your co-worker share the same project?
  • You also want to take action for the environment and better control your energy consumption.
Then we have a special offer for you for a limited period of time

Further information (Industry Mall)

SIMATIC Field PG – Get an impression!

SIMATIC Field PG – Ready to use

SIMATIC Field PG in a typical service mission

For mobile operations in industrial plants, the SIMATIC Field PG offers both rugged hardware and pre-installed TIA Portal engineering software for fast and efficient configuring, commissioning, service and maintenance.

Thanks to the semi-ruggedized design, the SIMATIC Field PG is especially suitable for use in harsh industrial environments: From engineering of a plant in an office-like environment to testing and servicing close to a machine, all the way to maintenance jobs on the factory floor, everything is possible.

Early in the morning Michael is preparing his service assignment: in the office he connects his SIMATIC Field PG to several monitors. With TIA Portal program changes, control system and machines can be simulated and set up in a virtual environment beforehand. This can help to identify problems early and reduce service times.
8:30 am – preparations for the project: Early in the morning Michael is preparing his service assignment: in the office he connects his SIMATIC Field PG to several monitors. With TIA Portal program changes, control system and machines can be simulated and set up in a virtual environment beforehand. This can help to identify problems early and reduce service times.
10:45 am – on the way for a mission: Let’s go: Thanks to the practical backpack the SIMATIC Field PG is perfectly prepared. Its size allows the transportation of several tools and connection cables, so that they are protected against a harsh environment.
10:45 am – on the way for a mission: Let’s go: Thanks to the practical backpack the SIMATIC Field PG is perfectly prepared. Its size allows the transportation of several tools and connection cables, so that they are protected against a harsh environment.
10:55 am – arrival at site: The service assignment begins with the arrival at the facility or machine. Thanks to the latest hardware, integrated automation interface and pre-installed software Michael is well equipped with the SIMATIC Field PG.
10:55 am – arrival at site: The service assignment begins with the arrival at the facility or machine. Thanks to the latest hardware, integrated automation interface and pre-installed software Michael is well equipped with the SIMATIC Field PG.
Early in the morning Michael is preparing his service assignment: in the office he connects his SIMATIC Field PG to several monitors. With TIA Portal program changes, control system and machines can be simulated and set up in a virtual environment beforehand. This can help to identify problems early and reduce service times.
11:00 am – ready-to-run: SIMATIC Field PG is immediately ready-to-run. Due to the pre-installed and system-tested engineering software TIA Portal, SIMATIC Field PG allows a quick and efficient commissioning, service and maintenance.
Early in the morning Michael is preparing his service assignment: in the office he connects his SIMATIC Field PG to several monitors. With TIA Portal program changes, control system and machines can be simulated and set up in a virtual environment beforehand. This can help to identify problems early and reduce service times.
12.30 pm - flexible connection to automation: Michael connects directly to the machine via PROFINET interfaces. Alternatively, also WLAN, Bluetooth and PROFIBUS interfaces are available. Direct programming of SIMATIC memory cards is also possible.
03.40 pm – mobile and robust: The long battery life allows him to work in the plant without the necessity of a power outlet. The lightweight magnesium casing of SIMATIC Field PG is so solid that it withstands shocks, vibrations and electromagnetic radiation near machines.
03.40 pm – mobile and robust: The long battery life allows him to work in the plant without the necessity of a power outlet. The lightweight magnesium casing of SIMATIC Field PG is so solid that it withstands shocks, vibrations and electromagnetic radiation near machines.
Early in the morning Michael is preparing his service assignment: in the office he connects his SIMATIC Field PG to several monitors. With TIA Portal program changes, control system and machines can be simulated and set up in a virtual environment beforehand. This can help to identify problems early and reduce service times.
04:45 pm – service assignment finished: Rubber-buffered corners protect SIMATIC Field PG during transportation. Thanks to the stable carrying handle it fits perfectly for mobile use like service assignments – and now have a nice evening. Thank you, Michael!

High-performance programming

• Maximum performance, optimized for efficient engineering

• Ready-to-run through pre-installed, system-tested programming software

• High-resolution display to relieve the eyes and support ergonomic operation

• Complete package comprising hardware and software with an unrivaled price/performance ratio

• Best possible availability thanks to highest quality, 'Made in Germany', exclusive development and manufacturing in Karlsruhe

Design

• Rugged hardware throughout:  lightweight magnesium enclosure

• Designed to withstand shocks and vibrations with rubber bumpers on device corners

• Integrated Interfaces for direct machine and plant connectivity

• Option for connecting external monitors via DVI-I or Display Port as well as an USB docking station for the normal office environment

Fit for industry

• Complete shielding against electromagnetic interference (EMC/EMS tested)

• Dirt resistant industrial design with dark color scheme and high-contrast keyboard with abrasion-resistant laser inscription

• Lightweight, compact power supply and a safe grip facilitate mobile use in alternating sites of operation

Take-aways

• Two configurable versions

• Available with licenses for trial, TIA Portal or Combo (TIA Portal + predecessor) pre-installed TIA Portal engineering software for fast and efficient configuring, commissioning and service

Technical Data

The SIMATIC Field PG M6 is available in two performance choices and can be individually configured: > Field PG Configurator

Features
M6 Comfort
M6 Advanced
Processor
 Intel® Core™ i5-8400H
(8th generation, 4 cores, 8 threads),
8 MB Cache,
up to 4.2 GHz
with turbo boost technology
Intel®Core™ i7-8850H
(8th generation, 6 cores, 12 threads),
9 MB Cache,
up to 4.3 GHz
with turbo boost technology
Memory
8 / 16 / 32 GB DDR4-SDRAM, 2666 MHz
Solid State Drive (SSD)
250 GB, 500 GB, 2 TB (SATA 6 Gb/s)
Graphics
Intel®UHD Graphics 630, 4K Support (4096 x 2304 Pixel @ 60Hz)
Display
15, 6 " wide screen, 300 cd
Resolution
Full-HD (1920 x 1080 Pixel)
Optical Drive
Dual layer multi standard DVD - RW
Status LED
8 LEDs that can be read with the display cover opened or closed
Option

S5 online interface / S5 EPROM programmer, incl. STEP 5 license, S5 AG cable and S5 EPROM adapter



Interfaces

2 x Gigabit Ethernet (10 / 100 / 1000 MBit) / PROFINET

1 x MPI/PROFIBUS

2 x USB 3.0 Type A (1 x 1.5 A charging feature while power off),

2 x USB 3.1 Gen2 Type A / Type C

1 x COM 1

1 x SIMATIC Memory Card, 1 x SIMATIC Multimedia Card

1 x Smart card slot (ID card)

1 x Universal audio jack (in/out)

1 x Card-Reader (SD, SDHC UHS-II, MMC)

1 x DP Display Port (for external monitors or projectors, max. 4096 x 2304 Pixel)

1 x DVI-I (for external monitors or projectors)


Pre-installed engineering software (can be ordered as Trial, TIA Portal or Combo license)


STEP 7 Professional (based on TIA Portal) and STEP 7 Professional 2017

WinCC Advanced (based on TIA Portal) and WinCC flexible Advanced 2008

STEP 7 Safety and Distributed Safety

Startdrive

PLCsim

TIA Selection Tool

S7-PCT

Option: STEP 5



Operating system

Windows 10 Enterprise, 64-Bit MUI

SIMATIC Field PG – Get an impression!

SIMATIC Field PG – Get an impression!

Accessories

Accessories for SIMATIC Programming Devices

Accessories for SIMATIC Field PG are the ideal choice, which harmonizes optimally with the core products. We place the same quality requirements on our accessories as we do on our core products.

Tailor made, useful and rugged.

Back pack

Field PG not included

Li-ion battery

Li-ion battery

for working self-sufficient

Exchangable drive kit

inclusive pocket and screwdriver

Power supply

and country-specific power cable

Scope of delivery

• Laptop backpack

• Lightweight, space-saving power supply unit

• Country-specific power cable

• Powerful lithium-ion battery

• S5 EPROM adapter and S5 AG connecting cable (with hardware version M6 Advanced + S5 HW-option)

• DVI-I to VGA adapter

• Quick install guide – brief instructions for getting started quickly

Type
Description
Order directly in the Mall (Article-No.)
Backpack
Backpack, for SIMATIC Field PG
6ES7798-0DA02-0XA0
Memory Expansion
1x 8 GB DDR4 SD-RAM SO-DIMM, 2666 MHz
6ES7648-3AK00-0PA0

1x 16 GB DDR4 SD-RAM SO-DIMM, 2666 MHz
6ES7648-3AK10-0PA0
Exchangable SSD kit
SSD 256 GB (incl. protective case and Torx screw driver)
6ES7791-2BA24-0AA0

SSD 512 GB (incl. protective case and Torx screw driver)
6ES7791-2BA22-0AA0

SSD 2 TB (incl. protective case and Torx screw driver)
6ES7791-2BA25-0AA0
USB to SATA adaptor
USB 3.0 to SATA adaptor for exchangable drive kit, for SIMATIC Field PG M6/M5/M4/M3
6ES7790-1AA01-0AA0
Spare battery
Lithium-Ionen battery for SIMATIC Field PG M6, 8.25 Ah
6ES7798-0AA10-0XA0
MPI cable
MPI connecting cable between SIMATIC S7 and SIMATIC Field PG, 5m
6ES7901-0BF00-0AA0
S5 AG cable
S5 connecting cable between SIMATIC S5 and SIMATIC Field PG, 5m
6ES5734-2BF00
S5 EPROM adaptor
Adaptor for SIMATIC Field PG to program S5 EPROMs
6ES7798-0CA00-0XA0
SIMATIC software
SIMATIC IPC Image & Partition Creator V3.5, USB Flash-Drive
6ES7648-6AA13-5YA0
Software update service (SUS)
STEP 7 Prof. Combo SUS, download
6ES7810-5CC04-0YY2

STEP 7 Prof. im TIA Portal, SUS, download
6ES7822-1AE00-0YY0

STEP7 Safety Advanced SUS, download
6ES7833-1FC00-0YY0

WinCC Advanced SUS, download
6AV6613-0AA00-0AY0

For further accessories please contact your Siemens partner.

Type
Description
Order directly in the Mall (Article-No.)
Power supply
Power supply for SIMATIC Field PG M6, 100-240V~, 1.2A, 50-60 Hz, 19V=, 4.74A, without power cord
6ES7798-0GA05-0XA0
Power cords, 3m
3m for SIMATIC Field PG M6/M5/M4/M2
6ES7900-5AA00-0XA0

for Germany, France, Spain, The Netherlands, Belgium, Sweden, Austria, Finland
6ES7900-5AA00-0XA0

for UK
6ES7900-5BA00-0XA0

for Switzerland
6ES7900-5CA00-0XA0

for USA
6ES7900-5DA00-0XA0

for Italy
6ES7900-5EA00-0XA0

for China, incl. CCC certificate
6ES7900-5FA00-0XA0

For further accessories please contact your Siemens partner.
