Machine level visualization with SIMATIC HMI

The perfect combination of Operator Devices and Engineering Software

Equipment for monitoring and operator control is needed wherever people have to work with machinery and plants performing tasks A to Z. It is not difficult to find the right device for the specific task. The challenge is to find a solution that is future-proof and flexible, that can be integrated into higher-level networks, and that can also meet the ever-increasing demands for transparency and data provision. It's the interplay of excellent hardware even for requirements beyond standard applications and the HMI Software, Engineering SW as well as Runtime SW, that makes SIMATIC HMI the solution provider of your choice when you are looking for machine level HMI.

Brochure: "Machine-level visualization with SIMATIC HMI - Efficient to a new level"

Download PDF

HM und SPS en Shoutbox

Hybrid Event, abr 17 - abr 21

Hannover Messe 2023

No time to wait, time to change.
Experience how industrial Digital Enterprises can be part of the solution for a smarter, more sustainable world.

Get your free ticket now to be part of the Siemens experience at Hannover Messe, April 17th to 21st.
Onsite (Hall 9, stand D53) and online.

Get your free ticket

Basic HMI - Simple visualization tasks economically realized

Basic HMI is recommended for simple applications with a limited quantity scale and where the price-performance ratio is important in addition to a fast and intuitive operation.
The devices offer a brilliant display quality and high-power visualization. This significantly facilitates the operation even of simple machines and equipment. Through turnkey and flexible solutions, you also save valuable time during installation and engineering.
Devices can be easily configured using the WinCC Basic Engineering Software, a budget priced subset of WinCC (TIA Portal).

Advanced HMI - Panel based - Demanding tasks realized with a high level of convenience

If you are looking for a panel-based solution for more demanding applications with larger quantity scales, make a decision for Advanced HMI.

The user benefits from excellent functionality and a wide range of devices and applications, with key or touch operation. Both stationary and mobile solutions are available.

The Panels can be coveniently configured by employing WinCC Comfort or higher with a Runtime Module already pre-installed on the device.

Advanced HMI - PC-based - Efficient realization of even the most demanding and complex HMI tasks

If production places particularly high demands on the quantity and type of information that must be processed and documented, a PC-based system is recommended. It offers the appropriate options for sufficient storage space, processing power, and data connectivity.

The user can either opt for a centralized solution, in which the visualization and PC are a single unit, or for a decentralized solution with an industrial monitor or a thin client. No matter which option you choose, there are devices available for special envioronmental conditions as well.

Web-based Training

HMI Design Masterclass

Join the HMI Design Masterclass with our UX expert Oliver Gerstheimer and learn what makes great HMI design and how you and your users can benefit – conveniently at your computer and completely free of charge.

Become a better HMI designer

Added values SIMATIC HMI Panels and Panel PCs have proven their value in many different applications in all industrial sectors over many years. The range of the systems in use is just as wide as that of the applications and technologies in the respective plants.

The SIMATIC HMI product range allows solutions tailored to your specific requirements. Scalable from basic tasks to high performance configurations. The Configuration Software WinCC TIA Portal always provides exactly the functionality you need for your application, as it is always corresponding to the device you're choosing.

Added values included

Machine level visualization is much more than just a broad offer of panel hardware with different sizes and operating elements. Totally Integrated Automation and the idea of complete digitalization of the whole enterprise is demonstrated most obvious at the interface of man and machine or operator and process. SIMATIC HMI offers a solution portfolio that includes all the benefits of TIA, providing productivity, efficiency and usability.

Efficient Engineering with SIMATIC HMI

Create your visualization faster and more easily than ever before!
Take advantage of the unique library concept, smart editors, simulation and virtual commissioning!

Reuse proven components Searching for errors is just about the most irritating and time-consuming job an engineer has to do. That is why we have made the TIA Portal a smart system. Type conflicts in interconnection caused by multiple entries or missing data and tags are detected immediately in the engineering process. This saves a great deal of time when configuring with WinCC in the TIA Portal!

Avoid failure and multiple entries Don't waste valuable time on a new project because you have to start your engineering from scratch. The TIA Portal provides a comprehensive library that allows you to effortlessly archive and reuse old projects. It also contains a large number of preassembled elements. Once done, a task need not be repeated! A system that follows. This safe a lot of time while creating projects

Test and evaluation before commissioning Usability is a critical aspect in a visualization. Whenever you wish to test the usability of your engineering, you can simply use the TIA Portal Simulation function. You can test and analyze your configuration under "secured" realistic conditions in a virtual environment. Even before your end product has been commissioned, you can be sure that it will work correctly!

Innovative design & operation with SIMATIC HMI

Innovative operator control objects with dynamic or animated elements right out of the libraries of the engineering system, a Style Editor for creating screens according to your corporate design and hardware that supports even gesture control or multitouch as a means of controlling your machinery.

Make visualizing the calling card for your machine!

Effective & unique user interfaces Vivid visualizations represent an enormous advantage in terms of usability. Operators can grasp operating states and the like much more quickly. The TIA Portal provides innovative operator control objects with dynamic or animated elements especially for HMI user interfaces, making it even simpler to recognize values and monitor processes!

Fast fulfillment of design wishes The operator device is also a representative item for every piece of machinery – first impressions count, as they say. That is why the Style Editor integrated in the TIA Portal has a full range of settings that allow you to do justice to the corporate design of your end-customer or of your own company. The result is an even more individual appearance! Here too, Siemens provides numerous free templates, demonstration projects and libraries for its customers to download.

Efficient & intuitive operation Nowadays, we are all used to intuitive control via touchscreen thanks to our daily use of smartphones and tablets. The new generation of SIMATIC HMI operator devices makes even more use of touch functionalities. Depending on the model in question, you can configure gesture control or multitouch as a means of controlling your machinery – a simple task in the TIA Portal

Brilliant HMI devices from SIMATIC HMI

Machine-level visualization with SIMATIC HMI – Brilliant HMI devices: Use the right HMI device for your application!

Scalable for various applications Siemens' SIMATIC HMI portfolio contains a suitable device for every situation. Even if requirements change as time goes on: the widescreen format used throughout the range is just one element that ensures scalability and consistency across all of the families of devices. So you always have a tailor-made solution

Reliable under any conditions SIMATIC HMI provides a suitable panel version for virtually any production conditions. Various certificates or applications mean that the devices can be used in harsh outdoor conditions as well as in ultra-hygienic environments. So you don't need to worry about whether your panels will work

Making your process visible at any time Whatever the content, readability is the most essential characteristic that a user interface has to deliver. Every HMI solution features a non-reflecting, anti-glare, dimmable widescreen display. In the Outdoor Panel version, these characteristics are guaranteed by a fully automatic brightness sensor, so that you can always keep an eye on your process.

Protection – with certainty

Protect your investment, your know-how and ensure reliable operation!
Machine safety, information security and investment protection: Be sure to be on the right side with SIMATIC HMI

Reliable protection with minimal effort All HMI operator devices are ideally designed to suit the "Safety Integrated" concept. Failsafe inputs for safety switch elements such as emergency stop buttons can be directly connected, even to the basic Key Panels – or, as with the Mobile Panels, they are built into the device and can be connected via PROFIsafe, making it easy for you to increase your operational safety!

Comprehensive protection of your application The "Security Integrated" concept enables comprehensive protection of your operator device and all your sensitive data against unauthorized access. You can use the extensive user administration facility in the TIA Portal or the HMI device itself to set up access restrictions, for example, based on passwords and many other protective measures to ensure effective protection against manipulation!

Maximum safety of investment Siemens looks after the interests of its customers with 24-hour service and longterm availability of its components. And if a new generation of HMI devices is required, intelligent engineering makes sure that the changeover goes as smoothly as possible, so you can be sure that investing in SIMATIC HMI was a really sound decision!

Rapid commissioning

Reliable error detection and error analysis already during engineering means rapid commissioning and minimizing downtimes even in the case of device changes.
Waste no time with testing and servicing!

Openness with PC-based Automation

Machine-level visualization with SIMATIC HMI – Openess with PC-based: You and your applications remain flexible and independent!

Highest performance with PC-based systems

.... from machine-based embedded systems to high-end solutions with Industrial PCs

Everything on one device

… control and operate with a failsafe Software Controller – local and decentral

Easy integration of existing data

… high-level language, complex real-time algorithms, IT applications, existing recipes and data bases

References SIMATIC HMI Panels have proven their value in many different applications in all industrial sectors over many years

SDS tec GmbH

Germany

A Knack for green energy

SDS tec combines competence in control cabinet design and biogas
Robust SIMATIC HMI Comfort Outdoor for reliable operation for outdoor use
Efficient engineering with TIA Portal and WinCC enables an easy integration of new components

Read the success story

Steritech S.A.

France

A new look, durable in operation

A complete automation solution to make its autoclaves for sterile packaging for food and drugs
Today's technology fo tomorrow's production thanks to visualization provided by Trilogy and SIMATIC WinCC
Reliable operation, even under difficult conditions, with a SIMATIC IPC 477D Pro Panel PC with touch display

Read the success story

Kostad Steuerungsbau GmbH

Austria

Ready for tomorrows Technology

With components and know-how from the industry, Kostad builds charging stations for electrical mobility
Open Controller as an "all in one" device for industrial control and Windows applications
The ruggedness of the installed technology allows a service life of 10 years or more

Read the success story

Rhaetian Railway

Switzerland

Optimized operation and maintenance of the power network

Addition of Comfort Panels provides a greater quantity of data
Quicker reporting and logging of malfunctions
Setting course for the future with the modenization of the maintenance system

Read the success story

Turncable Wakeboard

Germany

King of the wave

New control solution for a wakepark in Bavaria
15-inch SIMATIC HMI Comfort Outdoor Panel for operation under all weather conditions
More time for each individual wakeboarder thanks to seamless integration with checkout systems

Read the success story

Hans Weber Mascinenfabrik GmbH

Germany

Visualization provides the finishing touch

The operation of wood grinders combines design with ergonomics
Efficient configuring of the many processing technologies through modular engineering
The SIMATIC HMI Comfort Panel offers an attractive and intuitive operating concept

Read the success story

Downloads & Support All about Machine-level HMI at a glance

Downloads

Manuals, Operating instructions etc.

Operator devices overview

Support

Services

Support Services

Within the framework of Online and Technical Support, Siemens Industry offers a wide range of services. Online Support, Technical Support...

Learn more

Spare Parts Services

Siemens Industry's spare parts services are available worldwide and provide smooth and fast supply of spare parts – and thus optimal plant availability.

Learn more

SITRAIN - Digital Industry Academy

Further education for all Siemens industrial products - directly from the manufacturer, individually, with the latest methods.

Learn more

Contact

The direct way to your SIMATIC HMI contact

You have questions concerning our SIMATIC HMI systems? You want to discuss your specific challenges with us or are looking for the right project partner? Contact our regional offices – we are looking forward to hearing from you!

Just contact us
