As versatile as your application

Due to its exceptional functionality, the intelligent SIRIUS 3RW55 soft starter can solve even the most difficult starting and stopping tasks simply and particularly gently. Integrated smart functions (for example, pump cleaning, pump stopping, automatic parameterization, condition monitoring) help operators to run their pumps smoothly. Thanks to the SIRIUS 3RW55 Failsafe soft starters with integrated Safe Torque Off (STO) functionality, safety-related applications can also be realized.

• Three-phase controlled for optimal motor start
• Integrated, safety-related shutdown for SIL 1/PL c and SIL 3/PL e (with STO)
• ATEX/IECEx-certified for use in hazardous areas
• Engineering in the TIA Portal
• A wide range of communications interfaces (PROFINET, PROFIBUS, EtherNet/IP, Modbus)

• Integrated HMI (Human-Machine-Interface) with colour display
• Media redundancy for reliable network availability
• Integration in the process control system PCS 7 V9.0 SP2 with the 3RW5 block library

The SIRIUS 3RW52 soft starter is an ideal alternative to star-delta starters. As an all-rounder, it covers all drive types.

• Three-phase controlled for optimal motor start
• Parameterization with rotary potentiometer
• A wide range of communications interfaces (PROFINET, PROFIBUS, EtherNet/IP, Modbus)
• HMI (Human-Machine-Interface) with display optional
• Engineering in the TIA Portal
• Integration in the process control system PCS 7 V9.0 SP2 with the 3RW5 block library

Thanks to their compact design, SIRIUS 3RW30/40/50 soft starters are the ideal solution for all standard applications.

• Two-phase controlled for standard applications
• Parameterization with rotary potentiometer
• Optional communications interface (PROFINET, PROFIBUS, EtherNet/IP, Modbus)
• Visualization of motor data via optional HMI or analog output
• Integrated motor overload and intrinsic device protection
• Engineering in the TIA Portal
• ATEX/IECEx-certified for use in hazardous areas

Test the new generation of 3RW55 soft starters and simply experience how easy commissioning is. With the SIRIUS Soft Starter ES software, you can set parameters, monitor and perform diagnostics for service tasks quickly and easily. You can set the device parameters of the 3RW55 directly from your PC or laptop.

You can use the Simulation Tool for Soft Starters (STS) to select the right devices for your application – as a desktop application or optimized for your mobile device. Your selection is then automatically transferred to the Siemens Industry Mall ready for ordering via a link.
