The whole guide consists of the following chapters:
General information and limitationsWe worked really hard to bring the Unified Comfort Panels to the market. Despite our greatest efforts, some software features did not make it to the first release version. But no worries, we are definitely going to fix this with one of the following updates. Please be aware of the following topics:
1. Differences between simulation in engineering and device runtime
Depending on the functionalities you are using, it may happen, that the simulation may behave slightly different compared to the runtime on the Unified Comfort Panel. Which functionalities are affected can be found here.
2. Differences between engineering and runtime functionality
We already activated some functionalitiesin the engineering that are not yet available on the device. That allows us to deliver this functionality just by providing a new firmware for the devices. There will be no need for you to get a new TIA Portal version. Which functionalities are affected can be found here.
InstallationWe always recommend to use the latest version of our TIA Portal Engineering Framework. The SIMATIC HMI Unified Comfort Panels are available from TIA Portal V16. For the download of the project to the device you need at least Update 1. Make sure, that you have installed the latest update to your engineering station. To do so, please use the Automation Software Updater, or the download the latest update from Siemens Industry Online Support here.
Projects that include a large number of the functions of WinCC Unified and the Unified Comfort Panels. The projects are available for all display sizes of the Unified Comfort Panels.
If you are already working in TIA Portal and you have some existing projects, this Add-In can help you to convert some existing data to WinCC Unified.
SIMATIC HMI Template Suite
A library full of ready to use screen templates you can reuse for your application. The tool based wizard allows you to configure your navigation structure and generate it automatically into your TIA Portal project.
Generation change manual
You are used to the SIMATIC HMI Comfort Panels and want to switch over now to the Unified Comfort Panels? Or are you completely new to SIMATIC HMI? This documentation containseverything you need to know.
