SIMATIC HMI Unified Comfort Panels and SIMATIC IPCs for WinCC Unified

Seeing what matters, in a brilliant way

The new SIMATIC HMI Unified Comfort Panels with high performance and latest technology

Be one of the first to learn about it!

WinCC Unified Community

Getting Started

Everything you need to get started smoothly

On this page we have collected all the information you need to get started with the WinCC Unified System. In addition to general information, you will also find demo projects and a guide for the changeover..

Learn more

Highlights The SIMATIC HMI Unified Comfort Panels allow you to implement innovative operating concepts, both now and in the future. Learn more about the highlights of the new generation of devices.

Multitouch operation with SIMATIC HMI Unified Comfort Panels

Ease operation with Multitouch

Operation by smartphone sets the standard: Multitouch technology makes controlling the Unified Comfort Panels both easy and elegant, combining maximum usability with high contrast colors and great readability.

SIMATIC HMI Unified Comfort Panels function as an Industrial Edge device

Siemens Industrial Edge-enabled

The new SIMATIC HMI Unified Comfort Panels are Edge-enabled. This opens up completely new possibilities, such as functional expansion by using apps and the processing and analysis of data directly at the machine.

SIMATIC HMI Unified Comfort Panels enable remote access via web client

Web Client for Remote Operation

The maintenance-free web client provides flexible remote access to the visualization, independent from the on-site operation at the device. It can be accessed via web browser without additional software.

Digital Enterprise Virtual Summit

The next generation of Comfort Panels

SIMATIC HMI Unified Comfort Panels with their capacitive multitouch displays (in sizes 7 to 21.5 inches) offer you all the freedom and possibilities you need to implement your innovative operating concepts. The panels are particularly powerful, allow the installation of apps and simplify scaling thanks to vector-based visualization.

Watch the expert video to learn more about the new SIMATIC HMI Unified Comfort Panels.

Unique features They’re stylish, extremely fast, flexible to use, and offer limitless opportunities for visualization: Here are some good points in favor of the new SIMATIC HMI Unified Comfort Panels.

SIMATIC HMI Unified Comfort Panels are available in many different screen sizes

Size doesn’t matter

All six sizes of the Unified Comfort Panels come with the same number of hardware interfaces and the same functionality. All you need to do is choose the right screen size, between 7 and 21.5 inches.

The SIMATIC HMI Unified Comfort Panels provide maximum security

Security Integrated

The proprietary operating system based on SIMATIC Industrial OS offers maximum security. You can deactivate or uninstall the interfaces and system apps you don’t need. Despite their open structure and expandability, the panels are more secure than ever.

The SIMATIC HMI Unified Comfort Panels offer maximum convenience

Comfort DNA remains

Although the hardware and software development is fundamentally new, the Comfort DNA is unmistakable: Automatic system backup and high quality are an essential part of the Unified Comfort Panels.

The SIMATIC HMI Unified Comfort Panels offer huge power

The power to do more

The new hardware offers much more power – for the secure execution of edge apps as well as for fast visualization. The system limits have been doubled at least, and tripled in some cases. That means a panel system can host much larger applications than before.

You can easily update the SIMATIC HMI Unified Comfort Panels

Everything under control

Security and firmware updates are downloaded onto the devices directly via the TIA Portal or the SIMATIC Automation Tool. That means it’s easy to keep your devices completely up to date and enjoy maximum security for many years.

The SIMATIC HMI Unified Comfort Panels are ready for industrial demands

Ready for the industry

The possibility to operate the Unified Comfort Panels with standard working gloves as well as the smart detection of operating errors (such as touching the screen with the ball of the hand) makes them ready for harsh industrial environments.

Portfolio Perfect visualization, innovative operating concepts, and simply endless opportunities: Using our SIMATIC HMI Unified Comfort Panels, you’ll get the most out of SIMATIC WinCC Unified on machine level.

From small to large, with Multitouch all the way

The SIMATIC HMI Unified Comfort Panels offer the same functionality in various screen sizes — The Unified Comfort Panels are available in six display sizes in standard and neutral design.

SIMATIC HMI Comfort Panels are available in Standard and Neutral design versions

Uniform functionality from 7 to 21.5 inches

All devices come with the same number of hardware interfaces and the same functionality – just select the perfect device for your needs based on the screen size.
Every Unified Comfort Panel is available in two design versions:
Standard design: With Siemens and SIMATIC HMI branding, and a silver-colored aluminum frame
Neutral design: No branding, and a black-colored aluminum frame

MTP700 Unified Comfort

Touch operation, 7" widescreen TFT display, 16 million colors, PROFINET interface, configurable from WinCC Unified Comfort V16, contains open-source software, which is provided free of charge

Technical Data

Order device in the Industry Mall

Order Starter Kit with price advantage

MTP1000 Unified Comfort

Touch operation, 10.1" widescreen TFT display, 16 million colors, PROFINET interface, configurable from WinCC Unified Comfort V16, contains open-source software, which is provided free of charge

Technical Data

Order device in the Industry Mall

Order Starter Kit with price advantage

MTP1200 Unified Comfort

Touch operation, 12.1" widescreen TFT display, 16 million colors, PROFINET interface, configurable from WinCC Unified Comfort V16, contains open-source software, which is provided free of charge

Technical Data

Order device in the Industry Mall

Order Starter Kit with price advantage

MTP1500 Unified Comfort

Touch operation, 15.6" widescreen TFT display, 16 million colors, PROFINET interface, configurable from WinCC Unified Comfort V16, contains open-source software, which is provided free of charge

Technical Data

Order device in the Industry Mall

Order Starter Kit with price advantage

MTP1900 Unified Comfort

Touch operation, 18.5" widescreen TFT display, 16 million colors, PROFINET interface, configurable from WinCC Unified Comfort V16, contains open-source software, which is provided free of charge

Technical Data

Order device in the Industry Mall

Order Starter Kit with price advantage

MTP2200 Unified Comfort

Touch operation, 21“.5 widescreen TFT display, 16 million colors, PROFINET interface, configurable from WinCC Unified Comfort V16, contains open-source software, which is provided free of charge

Technical Data

Order device in the Industry Mall

Order Starter Kit with price advantage

Product overview of Unified Comfort Panels

Download PDF

Apps The SIMATIC HMI Unified Comfort Panels come with support for Industrial Edge by default. This allows you to expand the functionality of the devices using apps.

Application example for edge apps on SIMATIC HMI Unified Comfort Panels

Industrial Edge applications in conjunction with the SIMATIC HMI Unified Comfort Panel

This application example provides you with free edge apps. Using the included documentation, you can commission them directly on your operator device and test them out.

Learn more

Introduction: How to use Industrial Edge on the Unified Comfort Panels

In this video you get to know the general possibilities of Siemens Industrial Edge on the Unified Comfort Panels.

Discover, how easy edge computing with Industrial Edge and SIMATIC HMI Unified Comfort Panels is

Edge Computing made easy!

Conventional data processing on the field level is often costly and time-consuming, isn’t very scalable, and isn’t necessarily secure. With Industrial Edge we bring typical IT standards like central software management to the machine in a way that’s industry-compliant.

In 12 minutes and 5 steps you’ll learn how easy edge computing really is.

Watch on youtube

Performance Insight

Performance Insight enables you to analyze and optimize the performance of machines and plants on the basis of current operating data. Define the key performance indicators and analyze the performance and availability in clearly laid out dashboards.

Energy Manager

The Energy Manager application records the energy consumption of your machines and plants distributed throughout the world. In this way, you not only achieve ISO 50001-conformant energy transparency, but you can also optimize your energy efficiency by means of a comprehensive analysis of energy costs and consumers.

Notifier

Convert your smartphone into a news ticker for your production: With Notifier, you are automatically notified of important messages from your plant – worldwide, via the cloud-based app or locally via your own Wi-Fi network for even faster response times.

System overview

SIMATIC WinCC Unified System auf einen Blick

SIMATIC WinCC Unified System at a glance

Enjoy an overview of the many opportunities offered by the SIMATIC WinCC Unified System, with the best possible combination of hardware and software. Get to know the new possibilities and benefits of the entire system.

Learn more

SIMATIC WinCC Unified Integrations ins TIA Portal

Fully integrated into TIA Portal

SIMATIC WinCC Unified projects are configured on a uniform basis in the proven Totally Integrated Automation Portal (TIA Portal). That means you can create and test all the key parameters for the visualization easily and efficiently.

Learn more

References

All Siemens references

Heizomat GmbH

Germany

Focus on design und usability

Simple implementation of new functions and expansion of existing heaters.
A solution based on industrial systems with excellent quality and spare parts availability.
Modern, intuitive heater control increases the quality of the overall system.

Read the success story

GALVA GmbH

Germany

Visualization with future-oriented technologies

The visualization is implemented four to five times faster.
Operate systems via a convenient and modern interface.
New possibilities with a fully web-enabled visualization solution.

Read the success story
