versicharge next generation of chargers

VersiCharge™ AC Series

Energizing the evolution of EV charging for commercial applications

With the demand for electric vehicles drastically increasing, there is a need for smart charging infrastructure to support – anywhere from offices, retail shops, hospitals, airports, universities and colleges, public parking garages and lots, schools, hotels, and multi-family dwellings, to even last mile logistic hubs. The VersiCharge AC series, now in its third generation, is the result of continuous development and improvement of EV chargers for over 10 years. This state-of-the-art product matches the needs and expectations of today's growing demand for fast, safe, and efficient EV charging solutions for various needs and applications.

Siemens VersiCharge AC series is perfect for any application

VersiCharge AC Level 2 EV Charger

  • Faster charging - 40A or 48A / up to 11.5 kW
  • Connects to one "child" charger by Wi-Fi within 20 feet line of sight
  • Open payment options
  • Secure billing
  • Delayed and planned charging
  • OCPP back-end
  • Compatible with all common EVs (Tesla requires adapter)
  • Wall or post mounted
  • Indoor and outdoor rated (NEMA 4/ IK 8)
  • 3-year warranty
  • 20-ft cable with integrated cable management
  • Easy-to-use app
  • Cloud-based services available for easy management
  • "Make-ready" electrical equipment available

Intuitive and flexible VersiCharge AC series chargers are compact, reliable, and easy to use.



VersiCharge AC chargers are perfect for any commercial application looking for a cost-effective AC charging solution. Enjoy many benefits and features, such as an easy-to-use app, flexible communication connections, open payment options, secure billing, faster charging, OCPP, and more.



VersiCharge AC chargers can be connected directly with customer preferred back-end systems, making it scalable and cost-efficient. Compatible with all common EVs and applicable charging standards, the VersiCharge is easy-to-use and offers comfort functions, such as delayed and planned charging, to ensure a high degree of customer convenience.

Charging mode

Level 2



AC Output power

40/48 amp / up to 11.5 kW



Vehicle connection

J1772 plug with 20 ft. cable & integrated cable management



Power supply voltage

Single phase: 208 V / 240 V AC, 60 Hz; 50 A / 60 A breaker required



Safety & Standards

cUL listed - According to UL 1998, UL 991, UL2594/CSA C22.2 No.280/NMX-J-677-ANCE, UL 2231-1/CSA C22.2 No.281.1/ NMX-J-668-1, UL 2231-2/CSA C22.2 No.281.2/NMX-J-668/2-ANCE, UL 2251/CSA C22.2 No.282/NMX-J-678-ANCE

EMC - FCC Part 15.247, FCC Part 15B, FCC Part 15C



Dimensions

16.10 in (H) x 7.09 in (W) x 3.78 in (D)



Weight

17 lbs



Rating

Indoor and outdoor, NEMA 4, IK 8



Operating altitude

9,840 ft



Software upgrade

Over-the-air (OTA)



Warranty

3-year warranty

VersiCharge AC chargers provide numerous communication interfaces and an easily scalable parent-child configuration.


Child units can be connected to the local network via Wi-Fi or Ethernet and can communicate with a parent unit. Connects one child unit by Wi-Fi (20 feet line of sight). Each unit is provided with one Ethernet port as well.

Maximizing your eMobility journey with EV charging services

You can rely on Siemens’ experienced engineers – in our more than 100 branch offices nationwide – to provide proven, responsive services that help maximize your investment for the future of your EV charging infrastructure.

Support & Services

For support, please contact +1 (855) 950-6339 or (800) 333-7421.



For service inquiries, please visit www.usa.siemens.com/createcase
